10 HP Pull-Start Engine
Z-10 Pull-Start Replacement Engine & Parts
The Briggs & Stratton® Pull-Start engine for your Cyclone Rake Z-10 is built to outlast and outperform consumer-grade engines many times over. We maintain a full selection of genuine Briggs & Stratton engine parts.
For easy ordering click on the yellow key number bubble in the drawing below. A small window will open where you can change the quantity of the part you’re ordering and add it right to your cart from there. Or you can scroll farther down the page and order from the more detailed list of parts.
Our engines are specifically designed to only be used with our Cyclone Rakes. They are designed with a 1" diameter, keyed shaft with a 3" reveal. Do not order an engine for a larger Cyclone Rake than what you own as it will not fit and function properly.
If you are unsure of the part you need, don’t see it listed here, or you are unsure of the model of your Briggs & Stratton engine, give our Product Technicians a call and we’ll get you back up and running.

Key # | Part # | Product Name | QTY | Price | |
---|---|---|---|---|---|
252 | 01-01-812 | Oil Drain Plug, for all Briggs & Stratton engines |
$12.99
| ||
254 | 01-01-301 | Shaft Key (Not shown) |
$2.00
| ||
294 | 01-01-298 | Exhaust Deflector Screw, #8-3/8 sheet metal screw |
$0.50
| ||
302h | 06-02-301 | 10 HP Briggs & Stratton Vanguard Pull-Start Engine Replacement w/hardware kit |
$1,015.00
| ||
303b | 01-01-1356 | Oil Fill Butterfly Cap |
$15.99
| ||
303a | 01-01-752 | Oil Fill Cap, for Briggs & Stratton Intek engine ONLY |
$11.00
| ||
304 | 01-01-758 | Spark Plug (Champion RC12YC, Bosch FR8DCX or equivalent) |
$13.99
| ||
308c | 06-01-012 | Air Filter Outer Cover for 8HP & 10HP engines |
$20.00
| ||
310b | 01-01-1353 | Recoil Starter, fits 6.5HP, 8HP, 9HP & 10HP Vanguard engines |
$169.00
|
