Cyclone Rake Comparison Chart

Choosing The Right Cyclone Rake Is Easy

This comparison chart highlights the product features for each of the five unique Cyclone Rake models. When choosing a lawn vacuum, remember there are no hard and fast rules about property size. Everyone’s needs are different. Sometimes smaller properties have more difficult requirements or heavier leaf cover than properties of larger acreage. Be sure to consider the number of trees that shed on your property and the actual lawn area. Also, consider whether your property is flat, hilly, open, or congested. Steep grades and tight spaces are better served by the Cyclone Rake Classic or Commander models. Larger mowers and properties with heavy leaf cover will benefit from the increased capacity and vacuum power of the Cyclone Rake Commercial PRO or XL models. For really tough property cleanup work, be sure to check out the 10HP, Cyclone Rake Z-10 with its industry leading 10-inch diameter vacuum system.

classic
classic Classic
commander Commander
commercial-pro Commercial PRO
xl
XL
Z-10
Z-10
Cyclone Rake Prices

List Price: $1,195

Pre-Season Sale
$1,095

List Price: $1,495

Pre-Season Sale
$1,345

List Price: $1,695

Pre-Season Sale
$1,545

List Price: $1,895

Pre-Season Sale
$1,745

List Price: $2,095

Pre-Season Sale
$2,045

Best for Smaller properties with slopes or congested areas Mid-size properties with moderate leaf cover Mid-size to large properties with heavy leaf cover Large properties,
estates or commercial use
Very large properties, estates or commercial use
Mower/Tractor Recommendations
Mower Guidelines 8 HP or larger. 10 HP or larger. 14 HP or larger 16 HP or larger 16 HP or larger.
Mower deck recommendations

26"-40" mower
deck widths

36"-46" mower
deck widths
38"-48" mower
deck widths
42"-54" mower
deck widths
42"-72" mower
deck widths
Product Specifications
Vacuum System 7-inch dia.
Vacuum System
8-inch dia. JetPath 8-inch dia. JetPath 8-inch dia. JetPath 10-inch dia. JetPath
Engine 5.5 HP Vanguard
(8.5 ft lbs torque)
6.5 HP Vanguard
(9.1 ft lbs torque)
6.5 HP Vanguard
(9.1 ft lbs torque)
8 HP Vanguard
(13.4 ft lbs torque)
10 HP Vanguard
(14.4 ft lbs torque)
Capacity 200 gallons
27 cubic feet
22 bushels
285 gallons
38 cubic feet
32 bushels
415 gallons
55 cubic feet
44 bushels
415 gallons
55 cubic feet
44 bushels
415 gallons
55 cubic feet
44 bushels
Impeller Miracle Impeller
4-blade
Miracle Impeller
4-blade
Hi-Flow
5-blade
Super-Flow
5-blade
Super-Flow
5-blade
Unloading method Standard Easy-Flow Easy-Flow Easy-Flow Easy-Flow
W x H x L 35” x 49” x 73” 43” x 49” x 73” 48” x 54 ” x 79” 48” x 54” x 79” 48” x 54” x 79”
Collector dumping angle 60° 60° 60° 60° 60°
Rigid dumping lock Yes Yes Yes Yes Yes
Hitch type 2-pin: Never jackknifes 2-pin: Never jackknifes 2-pin: Never jackknifes 2-pin: Never jackknifes 2-pin: Never jackknifes
Folds flat
for storage
Yes Yes Yes Yes Yes
Accessories Available
Estate Vacuum™ - 32 ft. Yes Yes Yes Yes Yes
Power Vacuum Pickup™ - 17 ft. Yes Yes Yes Yes Yes
Engine
Maintenance Kit
Yes Yes Yes Yes Yes
Roof Rack Carrier™ Yes Yes Yes Yes Yes
Power Unloader™ Yes Yes Yes Yes Yes
Wall Mount Kit Yes Yes Yes Yes Yes
3rd Wheel™
Jack Stand
Yes Yes Yes Yes Yes
Power Lift-Unloader Yes Yes Yes Yes Yes
3-point Hitch & Custom Hitches Yes Yes Yes Yes Yes
PRO Upgrades Available
Blue Diamond Liner Yes Yes Yes Yes Yes
Dual-PRO™
Super Wheels
Yes Yes Yes Yes Yes
Tuff-PRO™
Super Hose
Yes Yes Yes Yes Yes
Mower Deck Adapter(MDA) Yes Yes Yes Yes Yes
Dynamic E-Start Engine No No No Yes Yes



If you're not sure which Cyclone Rake model is best for your property, call our Customer Service Specialists toll-free at  888-531-7253.

We're here to help!
